hardenable free machining steel
with additions of S and Pb
Material number:
~ 1.1268+S and Pb
Standard AISI:
~ 1095; A100Pb
RoHS 2 – 2011/65/EU:
compliant
Machinability:
good up to very good
Hardening capability:
up to 64-66 HRc
Polishing ability:
not adapted for mirror polishing
Welding ability:
not adapted
Uses:
parts for watch movements and parts
and numerous industrial applications
LAW 100 Pb, A100 Pb, ~ AISI 1095 free cutting high carbon steel, (1.0 % C) non stainless, RoHS compliant.
Specially adapted for making parts in the watch industry, but also for other high precision small parts.
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in coils of apprx. 25-30kg
diam. 2.30 mm, tolerance ISO fg7
in spools
drawn
fg 7
651 kg
0
050 723 - 274.400|280 623 - 376.100
2-300
in-spools
drawn
fg-7-en
0.300
10501100300
Sandvik 20AP
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 1m bars
diam. 0.30 mm, tolerance ISO h7
special length
drawn
h 7
1 kg
0
280 102 - 0.820
0-300
special-length
drawn
h-7-en
1.600
10502101600
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, in 2m bars +/-20mm
diam. 1.60 mm, tolerance ISO h7
bars 2m
drawn
h 7
49 kg
0
260 723 - 49.050
1-600
bars-2m
drawn
h-7-en
3.500
10500703500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in coils of apprx. 25kg
diam. 3.50 mm, tolerance ISO fg7
in spools
drawn
fg 7
0 kg
0
0
3-500
in-spools
drawn
fg-7-en
1.330
10500701330
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in coils
diam. 1.33 mm, tolerance ISO fg7
in spools
drawn
fg 7
0 kg
0
0
1-330
in-spools
drawn
fg-7-en
5.100
10513105100
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, in 3m bars
pointed, chamfered, eddy current tested
diam. 5.10 mm, tolerance ISO h7
bars 3m
ground
h 7
5 kg
0
011 004 - 4.700
5-100
bars-3m
ground
h-7-en
5.200
10513105200
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
pointed, chamfered, eddy current tested
diam. 5.20 mm, tolerance ISO h7
bars 3m
ground
h 7
408 kg
0
170 310 - 407.700
5-200
bars-3m
ground
h-7-en
2.000
10502102000
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
pointed/chamfered
diam. 2.00 mm, tolerance ISO h7
bars 2m
drawn
h 7
0 kg
0
0
2-000
bars-2m
drawn
h-7-en
2.500
10502102500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
pointed/chamfered
diam. 2.50 mm, tolerance ISO h7
bars 2m
drawn
h 7
5 kg
0
040 320 - 0.200|040 919 - 4.500
2-500
bars-2m
drawn
h-7-en
2.300
10502102300
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, in 2m bars
diam. 2.30 mm, tolerance ISO h7
bars 2m
drawn
h 7
23 kg
0
041 012 - 23.100
2-300
bars-2m
drawn
h-7-en
2.700
10513102700
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground in 3m bars
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 2.70 mm, tolerance ISO h7
bars 3m
ground
h 7
308 kg
0
171 012 - 307.800
2-700
bars-3m
ground
h-7-en
5.400
10513105400
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, in 3m bars
pointed, chamfered, eddy current tested
diam. 5.40 mm, tolerance ISO h7
bars 3m
ground
h 7
489 kg
0
180 402 - 116.100|071 201 - 372.800
5-400
bars-3m
ground
h-7-en
1.100
10503101100
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, polished, in 3m bars
diam. 1.10 mm, tolerance ISO h7
bars 3m
drawn
h 7
23 kg
0
280 105 - 0.304|101 005 - 22.530
1-100
bars-3m
drawn
h-7-en
5.000
10513005000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
RoHS directive conforme
cold drawn, annealed, ground polished,
stress relieved
in 3m bars (+40/0 mm)
end of bars: pointed, chamfered,
100% eddycurrent crack tested cl. 4
diam. 5.00 mm, tolerance ISO 286-2/h6
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
conforme EG/2002/95 ROHS directive
cold drawn, ground polished, stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 7.00 mm, tolerance ISO h6
LAW 100 Pb
no 1.1268+Pb, ~ AISI 1095
freecutting high carbon steel, RoHS conforme
cold drawn, annealded, ground, polished,
stress relieved execution
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered cl. 4
100% eddy current crack tested
diam. 3.00 mm, tolerance ISO h6
bars 3m
ground
h 6
1528 kg
1600
151 123 - 433.609|080 224 - 1094.150
3-000
bars-3m
ground
h-6-en
4.000
10513004000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground, polished,stress relieved
in 3m round bars (+30/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 4.00 mm, tolerance ISO h6
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground polished, stress relieved
in 3m bars (+40/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 6.00 mm, tolerance ISO 286-2/h6
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
diam. 0.50 mm, tolerance +/-0.0025
bars 2m
drawn
spec.
1 kg
0
180 194 - 0.833
0-500
bars-2m
drawn
spec-en
3.300
10513103300
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+30/0mm)
pointed, chamfered end of bars
eddycurrent crack tested
diam. 3.30 mm, tolerance ISO h7
bars 3m
ground
h 7
288 kg
0
190 209 - 288.300
3-300
bars-3m
ground
h-7-en
6.500
10513106500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, in 3m bars
pointed, chamfered, eddy current tested
diam. 6.50 mm, tolerance ISO h7
bars 3m
ground
h 7
20 kg
0
170 408 - 19.600
6-500
bars-3m
ground
h-7-en
2.000
10500702000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, in coils of apprx. 25 kg
diam. 2.00 mm, tolerance ISO fg7
in spools
drawn
fg 7
130 kg
500
200 923 - 129.600
2-000
in-spools
drawn
fg-7-en
2.100
10500702100
LAW 100 Pb
no 1.1268+Pb, ~-AISI 1095
freecutting high carbon steel
precisely cold drawn, in coils for ESCO
diam. 2.10 mm, tolerance ISO fg7
in spools
drawn
fg 7
343 kg
0
081 221 - 343.000
2-100
in-spools
drawn
fg-7-en
1.900
10503201900
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars
diam. 1.90 mm, tolerance ISO h8
bars 3m
drawn
h 8
8 kg
0
020 590 - 8.165
1-900
bars-3m
drawn
h-8-en
1.000
10502101000
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
diam. 1.00 mm, tolerance ISO h7
bars 2m
drawn
h 7
46 kg
0
300 113 - 46.292
1-000
bars-2m
drawn
h-7-en
1.400
10503101400
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars
diam. 1.40 mm, tolerance ISO h7
bars 3m
drawn
h 7
83 kg
0
221 117 - 24.800|110 320 - 57.800
1-400
bars-3m
drawn
h-7-en
1.500
10503101500
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
Material complies with the RoHS Directive
cold drawn, in 3m bars
diam. 1.50 mm, tolerance ISO h7
bars 3m
drawn
h 7
72 kg
0
170 719 - 71.800
1-500
bars-3m
drawn
h-7-en
1.600
10503101600
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars (+30/0mm)
diam. 1.60 mm, tolerance ISO h7
bars 3m
drawn
h 7
98 kg
0
080 620 - 33.400|260 723 - 64.700
1-600
bars-3m
drawn
h-7-en
1.700
10503101700
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars
diam. 1.70 mm, tolerance ISO h7
bars 3m
drawn
h 7
84 kg
0
070 208 - 50.089|300 915 - 34.200
1-700
bars-3m
drawn
h-7-en
1.800
10503101800
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars
pointed/chamfered
diam. 1.80 mm, tolerance ISO h7
bars 3m
drawn
h 7
74 kg
0
200 923 - 74.350
1-800
bars-3m
drawn
h-7-en
2.100
10503102100
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars
diam. 2.10 mm, tolerance ISO h7
bars 3m
drawn
h 7
20 kg
0
190 308 - 20.100
2-100
bars-3m
drawn
h-7-en
7.500
10513107500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
pointed, chamfered, eddy current tested
diam. 7.50 mm, tolerance ISO h7
bars 3m
ground
h 7
0 kg
0
0
7-500
bars-3m
ground
h-7-en
8.000
10513208000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
conforme EG/2002/95 ROHS directive
cold drawn, ground, in 3m bars
pointed, chamfered, eddy current tested
diam. 8.00 mm, tolerance ISO h8
bars 3m
ground
h 8
310 kg
0
010 313 - 309.700
8-000
bars-3m
ground
h-8-en
1.650
10513201650
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, in 3m bars
diam. 1.65 mm, tolerance ISO h8
bars 3m
ground
h 8
19 kg
0
041 186 - 19.146
1-650
bars-3m
ground
h-8-en
1.600
10500701600
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
precisely cold drawn, in coils
diam. 1.60 mm, tolerance ISO fg7
in spools
drawn
fg 7
479 kg
0
260 723 - 479.100
1-600
in-spools
drawn
fg-7-en
0.500
10500100500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in coils
diam. 0.50 mm, tolerance ISO h7
in spools
drawn
h 7
40 kg
0
160 689 - 40.000
0-500
in-spools
drawn
h-7-en
0.850
10500800850
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
precisely cold drawn, tensile Rm 900-1000MPa
in coils of apprx. 20kg, RID 300mm
diam. 0.85 mm, tol. -0.005/-0.012mm
in spools
drawn
spec.
0 kg
0
0
0-850
in-spools
drawn
spec-en
1.000
10500701000
LAW 100 Pb
German no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, in coils
diam. 1.00 mm, tolerance ISO fg7
in spools
drawn
fg 7
453 kg
0
161 019 - 453.000
1-000
in-spools
drawn
fg-7-en
1.100
10500701100
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in coils of apprx. 20kg
diam. 1.10 mm, tolerance ISO fg7
in spools
drawn
fg 7
268 kg
0
200 520 - 268.150
1-100
in-spools
drawn
fg-7-en
1.200
10500701200
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
precisely cold drawn, in coils of ~20kg
diam. 1.20 mm, tolerance ISO fg7
in spools
drawn
fg 7
1738 kg
800
060 324 - 615.800|080 524 - 1122.300
1-200
in-spools
drawn
fg-7-en
1.300
10500701300
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in coils of apprx. 20kg
diam. 1.30 mm, tolerance ISO fg7
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, crack tested
in coils of ~15-20kg
diam. 1.40 mm, tolerance ISO fg7
in spools
drawn
fg 7
465 kg
0
301 123 - 464.900
1-400
in-spools
drawn
fg-7-en
1.500
10500701500
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
horological grade, RoHS conforme
cold drawn, polished,
in coils of apprx. 20kg
diam. 1.50 mm, tolerance ISO fg7
in spools
drawn
fg 7
743 kg
0
170 719 - 435.300|280 224 - 307.800
1-500
in-spools
drawn
fg-7-en
1.700
10500701700
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in coils
diam. 1.70 mm, tolerance ISO fg7
in spools
drawn
fg 7
638 kg
0
070 208 - 26.700|141 010 - 610.800
1-700
in-spools
drawn
fg-7-en
1.800
10500701800
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, in coils of 20-25kg
diam. 1.80 mm, tolerance ISO fg7
in spools
drawn
fg 7
649 kg
0
170 424 - 649.000
1-800
in-spools
drawn
fg-7-en
0.500
10502100500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
diam. 0.50 mm, tolerance ISO h7
bars 2m
drawn
h 7
18 kg
0
090 974 - 18.351
0-500
bars-2m
drawn
h-7-en
0.850
10502100850
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
diam. 0.85 mm, tolerance ISO h7
bars 2m
drawn
h 7
13 kg
0
060 799 - 13.007
0-850
bars-2m
drawn
h-7-en
1.200
10502101200
Sandvik 20AP
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
diam. 1.20 mm, tolerance ISO h7
bars 2m
drawn
h 7
76 kg
0
210 819 - 75.840
1-200
bars-2m
drawn
h-7-en
1.300
10502101300
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
diam. 1.30 mm, tolerance ISO h7
bars 2m
drawn
h 7
63 kg
0
201 021 - 63.379
1-300
bars-2m
drawn
h-7-en
1.400
10502101400
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
diam. 1.40 mm, tolerance ISO h7
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
diam. 0.85 mm, tolerance ISO h8
bars 2m
drawn
h 8
27 kg
0
270 286 - 27.344
0-850
bars-2m
drawn
h-8-en
1.000
10503101000
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars
diam. 1.00 mm, tolerance ISO h7
bars 3m
drawn
h 7
52 kg
0
300 113 - 28.466|161 019 - 23.400
1-000
bars-3m
drawn
h-7-en
1.200
10503101200
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars +/-15mm
diam. 1.20 mm, tolerance ISO h7
bars 3m
drawn
h 7
139 kg
0
210 819 - 139.200
1-200
bars-3m
drawn
h-7-en
1.300
10503101300
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars
diam. 1.30 mm, tolerance ISO h7
bars 3m
drawn
h 7
63 kg
0
120 122 - 39.400|231 122 - 23.600
1-300
bars-3m
drawn
h-7-en
4.800
10513104800
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, in 3m bars
pointed, chamfered, eddy current tested
diam. 4.80 mm, tolerance ISO h7
bars 3m
ground
h 7
137 kg
0
020 206 - 137.100
4-800
bars-3m
ground
h-7-en
9.000
10513009000
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 9.00 mm, tolerance ISO h6
bars 3m
ground
h 6
907 kg
0
280 922 - 30.748|070 224 - 891.200
9-000
bars-3m
ground
h-6-en
1.700
10502101700
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
diam. 1.70 mm, tolerance ISO h7
bars 2m
drawn
h 7
12 kg
0
011 101 - 12.300
1-700
bars-2m
drawn
h-7-en
2.450
10500702450
LAW 100 Pb
no 1.1268+Pb, ~AISIi 1095
freecutting high carbon steel
cold drawn, in coils of ~25kg
diam. 2.45 mm, tolerance ISO fg7
in spools
drawn
fg 7
0 kg
0
0
2-450
in-spools
drawn
fg-7-en
0.700
10500100700
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in coils
diam. 0.70 mm, tolerance ISO h7
in spools
drawn
h 7
25 kg
0
160 689 - 24.610
0-700
in-spools
drawn
h-7-en
0.600
10500700600
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, polished
on spools type SK370
diam. 0.60 mm, tolerance ISO fg7
in spools
drawn
fg 7
167 kg
0
090 620 - 166.800
0-600
in-spools
drawn
fg-7-en
4.700
10513104700
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, in 3m bars
pointed, chamfered, eddy current tested
diam. 4.70 mm, tolerance ISO h7
bars 3m
ground
h 7
546 kg
0
250 205 - 49.779|290 212 - 496.600
4-700
bars-3m
ground
h-7-en
3.700
10513103700
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground polished,
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 3.70 mm, tolerance ISO h7
bars 3m
ground
h 7
80 kg
0
230 512 - 79.850
3-700
bars-3m
ground
h-7-en
0.700
10502100700
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
diam. 0.70 mm, tolerance ISO h7
bars 2m
drawn
h 7
55 kg
0
160 689 - 55.117
0-700
bars-2m
drawn
h-7-en
2.300
10500302300
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn wire, annealed for redrawing
diam. 2.30 mm, tolerance ISO h9
in spools
drawn
h 9
1615 kg
0
270 923 - 1426.000|140 224 - 189.000
2-300
in-spools
drawn
h-9-en
8.000
10513008000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
conforme EG/2002/95 ROHS directive
cold drawn, annealed, ground, polished,
stress relieved, in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 8.00 mm, tolerance ISO h6
bars 3m
ground
h 6
849 kg
0
040 919 - 20.826|260 122 - 828.500
8-000
bars-3m
ground
h-6-en
4.100
10513104100
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+30/0mm)
pointed, chamfered, eddy current tested
diam. 4.10 mm, tolerance ISO h7
bars 3m
ground
h 7
460 kg
0
290 812 - 459.900
4-100
bars-3m
ground
h-7-en
4.300
10513104300
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 4.30 mm, tolerance ISO h7
bars 3m
ground
h 7
271 kg
0
020 605 - 270.650
4-300
bars-3m
ground
h-7-en
0.800
10502000800
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
precisely cold drawn, in 2m bars
diam. 0.80 mm, tolerance ISO h6
bars 2m
drawn
h 6
12 kg
0
160 408 - 11.551
0-800
bars-2m
drawn
h-6-en
8.500
10513108500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished,i
in 3m bars (+40/0mm)
end of bars: pointed and chamfered
100% eddy current crack tested
diam. 8.50 mm, tolerance ISO h7
bars 3m
ground
h 7
274 kg
0
031 111 - 274.000
8-500
bars-3m
ground
h-7-en
0.350
10501000350
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 1m bars
diam. 0.35 mm, tolerance ISO h6
special length
drawn
h 6
0 kg
0
120 107 - 0.307
0-350
special-length
drawn
h-6-en
0.450
10501000450
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 1m bars
diam. 0.45 mm, tolerance ISO h6
special length
drawn
h 6
1 kg
0
160 689 - 0.593
0-450
special-length
drawn
h-6-en
0.900
10503100900
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars
diam. 0.90 mm, tolerance ISO h7
bars 3m
drawn
h 7
12 kg
0
180 806 - 12.090
0-900
bars-3m
drawn
h-7-en
2.330
10500102330
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in coils
diam. 2.33 mm, tolerance ISO h7
in spools
drawn
h 7
37 kg
0
110 305 - 36.500
2-330
in-spools
drawn
h-7-en
13.000
10513113000
Law 100Pb
DIN A-100Pb ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
pointed, chamfered, eddy current tested
diam. 13.00 mm, tolerance ISO h7
bars 3m
ground
h 7
0 kg
0
0
13-000
bars-3m
ground
h-7-en
0.450
10500000450
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, on spools
diam. 0.45 mm, tolerance ISO h6
in spools
drawn
h 6
0 kg
0
120 107 - 0.493
0-450
in-spools
drawn
h-6-en
3.200
10500703200
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, in coils
diam. 3.20 mm, tolerance ISO fg7
in spools
drawn
fg 7
0 kg
0
0
3-200
in-spools
drawn
fg-7-en
0.650
10501000650
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 1m bars
diam. 0.65 mm, tolerance ISO h6
special length
drawn
h 6
0 kg
0
160 689 - 0.331
0-650
special-length
drawn
h-6-en
8.800
10513008800
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground polished
in 3m bars (+40/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 8.80 mm, tolerance ISO h6
bars 3m
ground
h 6
582 kg
0
180 215 - 582.000
8-800
bars-3m
ground
h-6-en
0.400
10502100400
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
diam. 0.40 mm, tolerance ISO h7
bars 2m
drawn
h 7
0 kg
0
120 107 - 0.060
0-400
bars-2m
drawn
h-7-en
2.500
10513002500
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground polished, stress relived
in 3m bars (+30/0mm)
end of bars: pointed,chamfered
100% eddycurrent crack tested cl. 4
diam. 2.50 mm, tolerance ISO h6
bars 3m
ground
h 6
1699 kg
0
130 324 - 1699.200
2-500
bars-3m
ground
h-6-en
1.750
10500601750
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in coils of 20 +/-5kg
diam. 1.75 mm, tolerance ISO fg6
in spools
drawn
fg 6
77 kg
370
290 524 - 167.100
1-750
in-spools
drawn
fg-6-en
8.100
10513108100
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
pointed, chamfered, eddy current tested
diam. 8.10 mm, tolerance ISO h7
bars 3m
ground
h 7
738 kg
0
180 614 - 738.000
8-100
bars-3m
ground
h-7-en
0.900
10500600900
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
precisely cold drawn, in coils
diam. 0.90 mm, tolerance ISO fg6
in spools
drawn
fg 6
46 kg
0
191 207 - 46.196
0-900
in-spools
drawn
fg-6-en
0.800
10500600800
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
precisely cold drawn,
in coils of apprx. 10-12kg, ID ~300mm
diam. 0.80 mm, tolerance ISO fg6
in spools
drawn
fg 6
1 kg
0
160 408 - 1.296
0-800
in-spools
drawn
fg-6-en
0.600
10500600600
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
precisely cold drawn, in coils
diam. 0.60 mm, tolerance ISO fg6
in spools
drawn
fg 6
0 kg
0
0
0-600
in-spools
drawn
fg-6-en
0.600
10502000600
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
precisely cold drawn, in 2m bars
diam. 0.60 mm, tolerance ISO h6
bars 2m
drawn
h 6
0 kg
0
0
0-600
bars-2m
drawn
h-6-en
0.700
10502000700
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
precisely cold drawn, in 2m bars
diam. 0.70 mm, tolerance ISO h6
bars 2m
drawn
h 6
25 kg
0
191 207 - 24.746
0-700
bars-2m
drawn
h-6-en
0.700
10500600700
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
precisely cold drawn, in coils
diam. 0.70 mm, tolerance ISO fg6
in spools
drawn
fg 6
9 kg
0
191 207 - 8.700
0-700
in-spools
drawn
fg-6-en
3.100
10500703100
LAW 100 Pb
no 1.1268+Pb, ~AISI1095
freecutting leaded high carbon steel
precisely cold drawn, in coils
diam. 3.10 mm, tolerance ISO fg7
in spools
drawn
fg 7
546 kg
0
161 111 - 546.000
3-100
in-spools
drawn
fg-7-en
4.500
10513004500
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground polished
in 3m bars (+40/0 mm)
end o bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 4.50 mm, tolerance ISO h6
bars 3m
ground
h 6
717 kg
0
140 819 - 716.630
4-500
bars-3m
ground
h-6-en
5.800
10513005800
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 5.80 mm, tolerance ISO h6
bars 3m
ground
h 6
414 kg
0
050 619 - 414.100
5-800
bars-3m
ground
h-6-en
1.100
10503001100
LAW 100 Pb
no 1.1268+Pb ~Aisi 1095
freecutting high carbon steel
cold drawn, polished, in 3m bars
Rm: 850-1100MPa
diam. 1.10 mm, tolerance ISO h6
bars 3m
drawn
h 6
39 kg
0
211 112 - 38.601
1-100
bars-3m
drawn
h-6-en
2.300
10513002300
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground polished
in 3m bars (+30/0mm)
end of bars: pointed and chamfered
100% eddycurrent crack tested
diam. 2.30 mm, tolerance ISO h6
bars 3m
ground
h 6
740 kg
0
160 113 - 241.600|300 113 - 498.500
2-300
bars-3m
ground
h-6-en
12.000
10513012000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
conforme EG/2002/95 ROHS directive
cold drawn, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 12.00 mm, tolerance ISO h6
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 13.00 mm, tolerance ISO h6
bars 3m
ground
h 6
837 kg
0
211 112 - 254.699|140 318 - 582.200
13-000
bars-3m
ground
h-6-en
14.000
10513014000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 14.00 mm, tolerance ISO h6
bars 3m
ground
h 6
8 kg
0
300 518 - 7.600
14-000
bars-3m
ground
h-6-en
2.400
10513002400
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl.4
diam. 2.40 mm, tolerance ISO h6
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 7.50 mm, tolerance ISO h6
bars 3m
ground
h 6
825 kg
0
221 123 - 119.800|100 124 - 705.000
7-500
bars-3m
ground
h-6-en
3.200
10513003200
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground polished,
in 3m bars (+30/0mm)
end of bars: pointed, chamfered bars
100% eddycurrent crack tested
diam. 3.20 mm, tolerance ISO h6
bars 3m
ground
h 6
727 kg
0
011 014 - 727.350
3-200
bars-3m
ground
h-6-en
10.000
10513010000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095 (20AP)
freecutting high carbon steel
RoHS directive conforme
cold drawn, annealed, ground, polished.
stress relieved, in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 10.00 mm, tolerance ISO 286-2/h6
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground polished,
in 3m bars +30/0 mm
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 2.60 mm, tolerance ISO h6
bars 3m
ground
h 6
317 kg
0
051 213 - 317.070
2-600
bars-3m
ground
h-6-en
2.000
10513902000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground, polished
stress relieved
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested cl.4
diam. 2.00 mm, tolerance ISO 286-2/h5
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, annealed, ground, polished,
stress relieved
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 3.00 mm, tolerance ISO h5
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel, RoHS conforme
cold drawn, ground, polished, stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current tested cl.4
diam. 9.00 mm, tolerance ISO h5
bars 3m
ground
h 5
678 kg
0
070 318 - 677.900
9-000
bars-3m
ground
h-5-en
8.000
10513908000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, annealed, ground, polished,
stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 8.00 mm, tolerance ISO h5
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished,
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 2.50 mm, tolerance ISO h5
bars 3m
ground
h 5
75 kg
300
090 414 - 75.300
2-500
bars-3m
ground
h-5-en
6.000
10513906000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel, RoHS conforme
cold drawn, ground, polished,stress relieved
in 3m bars (+40/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 6.00 mm, tolerance ISO h5
bars 3m
ground
h 5
905 kg
0
120 820 - 75.900|300 823 - 829.500
6-000
bars-3m
ground
h-5-en
5.000
10513905000
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
precisely cold drawn, ground, polished
stress relieved
in 3m bars (+40/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 5.00 mm, tolerance ISO h5
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, stress relieved,ground, polished,
in 2m bars (+30/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 3.00 mm, tolerance ISO h6
bars 2m
ground
h 6
465 kg
0
120 314 - 3.928|070 224 - 561.350
3-000
bars-2m
ground
h-6-en
1.600
10502001600
LAW 100 Pb
no 1.1268+Pb, ~AISI1095
freecutting high carbon steel
precisely cold drawn, Rm 850-1000 MPa
in 2m bars (+20/0 mm)
diam. 1.60 mm, tolerance ISO h6
bars 2m
drawn
h 6
12 kg
0
070 208 - 11.700
1-600
bars-2m
drawn
h-6-en
4.000
10513904000
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, annealed, ground, polished
stress relileved, in 3m bars (+30/0 mm)
end of bars:pointed, chamfered,
100% eddy currentcrack tested cl. 4
diam. 4.00 mm, tolerance ISO 286-2/h5
bars 3m
ground
h 5
1082 kg
0
140 722 - 189.270|111 023 - 905.600
4-000
bars-3m
ground
h-5-en
10.000
10513910000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, annealed, ground, polished,
stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 10.00 mm, tolerance ISO 286-2/h5
LAW 100 Pb
no 1.1268+Pb, ~ AISI 1095
freecutting high carbon steel
cold drawn, annealede,ground, polished,
stress relieved, in 3m bars (+30/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 3.50 mm, tolerance ISO 286-2/h6
bars 3m
ground
h 6
830 kg
0
190 220 - 27.144|280 622 - 803.900
3-500
bars-3m
ground
h-6-en
2.000
10512902000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, annealed, ground, polished
stress relieved, n 2m bars (+/-10 mm)
pointed/chamfered, eddycurent crack tested cl.4
diam. 2.00 mm, tolerance ISO 286-2/h5
bars 2m
ground
h 5
166 kg
0
250 123 - 245.651
2-000
bars-2m
ground
h-5-en
7.000
10513907000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 7.00 mm, tolerance ISO h5
bars 3m
ground
h 5
1114 kg
0
101 018 - 142.900|070 224 - 971.000
7-000
bars-3m
ground
h-5-en
3.600
10513003600
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground polished
in 3m bars (+30/0 mm)
end of bars: pointed, chamfered
eddycurrent crack tested cl. 4
diam. 3.60 mm, tolerance ISO h6
bars 3m
ground
h 6
917 kg
0
191 016 - 103.919|190 220 - 813.500
3-600
bars-3m
ground
h-6-en
1.300
10513901300
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, annealed, ground, polished,
stress relieved
in 3m bars (+30/0mm)
diam. 1.30 mm, tolerance ISO 286-2/h5
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 9.50 mm, tolerance ISO h6
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished,
in 1.5m round bars (+15/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 4.00 mm, tolerance ISO 286-2/h6
special length
ground
h 6
565 kg
0
270 923 - 564.500
4-000
special-length
ground
h-6-en
6.000
10511006000
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished,
in 1.5m round bars (+15/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 6.00 mm, tolerance ISO h6
special length
ground
h 6
163 kg
0
030 914 - 162.900
6-000
special-length
ground
h-6-en
2.500
10501102500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2.5m bars
diam. 2.50 mm, tolerance ISO h7
special length
drawn
h 7
0 kg
0
0
2-500
special-length
drawn
h-7-en
1.500
10513901500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+30/0 mm)
end of bars: chamfered
eddycurrent crack tested cl. 2
diam. 1.50 mm, tolerance ISO h5
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
Material complies with the RoHS Directive
cold drawn, annealed, ground polished
in 3m bars (+30/0mm)
end of bars: pointed,chamfered
100% eddycurrent crack tested cl. 4
diam. 2.80 mm, tolerance ISO 286-2/h6
bars 3m
ground
h 6
571 kg
0
101 121 - 46.600|280 224 - 524.000
2-800
bars-3m
ground
h-6-en
1.360
10500701360
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel, RoHS conform
cold drawn, in coils
diam. 1.36 mm, tolerance ISO fg7
in spools
drawn
fg 7
0 kg
250
0
1-360
in-spools
drawn
fg-7-en
5.500
10513905500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, in 3m bars
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 5.50 mm, tolerance ISO h5
bars 3m
ground
h 5
138 kg
0
161 111 - 137.900
5-500
bars-3m
ground
h-5-en
5.500
10513005500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, in 3m bars
end of bars: pointed, chamfered,
eddy current crack tested
diam. 5.50 mm, tolerance ISO h6
bars 3m
ground
h 6
842 kg
0
220 818 - 750.000|130 619 - 92.300
5-500
bars-3m
ground
h-6-en
3.500
10513903500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished, stress relieved
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 3.50 mm, tolerance ISO h5
bars 3m
ground
h 5
281 kg
0
050 918 - 282.319
3-500
bars-3m
ground
h-5-en
15.000
10513015000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 15.00 mm, tolerance ISO h6
bars 3m
ground
h 6
198 kg
0
210 116 - 198.000
15-000
bars-3m
ground
h-6-en
16.000
10513016000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 16.00 mm, tolerance ISO h6
bars 3m
ground
h 6
244 kg
0
070 116 - 244.491
16-000
bars-3m
ground
h-6-en
3.100
10513003100
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground polished,
in 3m bars (+30/0mm)
end of bars: pointed, chamfered bars
100% eddycurrent crack tested cl. 4
diam. 3.10 mm, tolerance ISO 286-2/h6
bars 3m
ground
h 6
976 kg
0
200 324 - 976.400
3-100
bars-3m
ground
h-6-en
3.000
10511003000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, annealed, ground, polished,
stress relieved
in 1.5m bars (+15/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 3.00 mm, tolerance ISO h6
special length
ground
h 6
77 kg
0
280 318 - 77.200
3-000
special-length
ground
h-6-en
2.300
10512902300
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished,
in 2m bars (+/- 10 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 2.30 mm, tolerance ISO h5
bars 2m
ground
h 5
0 kg
0
0
2-300
bars-2m
ground
h-5-en
6.600
10513906600
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
stress relieved, in 3m bars (+40/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 6.60 mm, tolerance ISO h5
bars 3m
ground
h 5
418 kg
0
100 816 - 98.700|140 617 - 319.000
6-600
bars-3m
ground
h-5-en
0.500
10500800500
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, on spools
diam. 0.50 mm, tolerance ISO h5
in spools
drawn
spec.
2 kg
0
090 620 - 1.500
0-500
in-spools
drawn
spec-en
11.000
10513011000
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, annealed, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 11.00 mm, tolerance ISO h6
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground polished
stress relieved
in 3m bars (+40/0 mm)
end of bars: pointed, chamfered,
DIN EN 10277-1
100% eddy current crack tested cl. 4
diam. 6.50 mm, tolerance ISO h6
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 12.00 mm, tolerance ISO h5
bars 3m
ground
h 5
616 kg
0
240 118 - 615.700
12-000
bars-3m
ground
h-5-en
1.800
10503901800
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars
pointed/chamfered
diam. 1.80 mm, tolerance ISO h5
bars 3m
drawn
h 5
92 kg
0
210 116 - 91.610
1-800
bars-3m
drawn
h-5-en
2.000
10503902000
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars
pointed/chamfered
diam. 2.00 mm, tolerance ISO h5
bars 3m
drawn
h 5
189 kg
0
210 116 - 188.766
2-000
bars-3m
drawn
h-5-en
2.000
10500602000
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in coils
diam. 2.00 mm, tolerance ISO fg6
in spools
drawn
fg 6
135 kg
0
210 116 - 135.100
2-000
in-spools
drawn
fg-6-en
1.600
10503901600
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars
pointed/chamfered
diam. 1.60 mm, tolerance ISO h5
bars 3m
drawn
h 5
11 kg
0
110 315 - 11.258
1-600
bars-3m
drawn
h-5-en
1.400
10503901400
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars
pointed/chamfered
diam. 1.40 mm, tolerance ISO h5
bars 3m
drawn
h 5
145 kg
0
110 315 - 144.864
1-400
bars-3m
drawn
h-5-en
1.500
10503901500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars
pointed/chamfered
diam. 1.50 mm, tolerance ISO h5
bars 3m
drawn
h 5
87 kg
0
110 315 - 87.344
1-500
bars-3m
drawn
h-5-en
5.700
10513005700
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished,
stress relieved
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 5.70 mm, tolerance ISO h6
bars 3m
ground
h 6
610 kg
0
130 619 - 610.000
5-700
bars-3m
ground
h-6-en
1.200
10512901200
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
precisely cold drawn, ground,
in 2m bars (+15/0mm)
diam. 1.20 mm, tolerance ISO h5
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
precisely cold drawn, ground,
in 2m bars (+15/0mm)
diam. 1.50 mm, tolerance ISO h5
bars 2m
ground
h 5
0 kg
0
0
1-500
bars-2m
ground
h-5-en
6.200
10513006200
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground polished
stress relieved
in 3m bars (+40/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 6.20 mm, tolerance ISO h6
bars 3m
ground
h 6
917 kg
0
280 819 - 916.600
6-200
bars-3m
ground
h-6-en
2.800
10500702800
LAW 100 Pb
no 1.1268+Pb, ~ AISI 1095
freecutting high carbon steel, RoHS conform
cold drawn, in coils of apprx.25kg
diam. 2.80 mm, tolerance ISO fg7
in spools
drawn
fg 7
225 kg
0
180 718 - 225.000
2-800
in-spools
drawn
fg-7-en
7.500
10513907500
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl.4
diam. 7.50 mm, tolerance ISO h5
bars 3m
ground
h 5
868 kg
0
160 518 - 868.100
7-500
bars-3m
ground
h-5-en
2.000
105011020001
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2.5m bars
diam. 2.00 mm, tolerance ISO h7
special length
drawn
h 7
0 kg
0
0
2-000
special-length
drawn
h-7-en
3.000
10501103000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, in 2.5m (+/-10mm) bars
diam. 3.00 mm, tolerance ISO h7
special length
drawn
h 7
0 kg
0
0
3-000
special-length
drawn
h-7-en
2.000
10513202000
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished,
in 3m bars (+30/0mm)
end of bars: pointed, chamfered
100% eddycurrent crack tested
diam. 2.00 mm, tolerance ISO h8
bars 3m
ground
h 8
25 kg
0
030 815 - 24.619
2-000
bars-3m
ground
h-8-en
3.800
10500303800
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn wire, annealed
on spools SH021 (~200kg/spool)
diam. 3.80 mm, tolerance ISO h9
in spools
drawn
h 9
0 kg
0
0
3-800
in-spools
drawn
h-9-en
5.000
10500305000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
annealed wire Rm 550-700MPa
on wooden spools SH021 (~200kg)
diam. 5.00 mm, tolerance ISO h9
in spools
drawn
h 9
847 kg
0
140 220 - 847.300
5-000
in-spools
drawn
h-9-en
4.200
10513004200
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+30/0mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 4.20 mm, tolerance ISO h6
bars 3m
ground
h 6
264 kg
0
130 814 - 263.692
4-200
bars-3m
ground
h-6-en
0.900
10500000900
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, on spool
diam. 0.90 mm, tolerance ISO h6
in spools
drawn
h 6
9 kg
0
300 113 - 8.800
0-900
in-spools
drawn
h-6-en
3.350
10500303350
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
annealed wire Rm 550-700MPa
on wooden spools SH021 (~200kg)
diam. 3.35 mm, tolerance ISO h9
in spools
drawn
h 9
0 kg
0
0
3-350
in-spools
drawn
h-9-en
5.000
105110050001
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground, polished,
in 2.5m round bars (+/-10 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 5.00 mm, tolerance ISO h6
special length
ground
h 6
0 kg
0
0
5-000
special-length
ground
h-6-en
4.000
105110040001
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished,
in 2.5m round bars (+15/0 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested
diam. 4.00 mm, tolerance ISO h6
special length
ground
h 6
0 kg
0
0
4-000
special-length
ground
h-6-en
6.000
105110060001
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished,
in 2.5m round bars (+/- 15mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 6.00 mm, tolerance ISO h6
special length
ground
h 6
0 kg
0
0
6-000
special-length
ground
h-6-en
8.000
10511008000
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
conforme EG/2002/95 ROHS directive
cold drawn, ground, polished,
in 2.5m bars (+/-10 mm)
end of bars: pointed, chamfered,
100% eddy current crack tested cl. 4
diam. 8.00 mm, tolerance ISO h6
special length
ground
h 6
0 kg
0
0
8-000
special-length
ground
h-6-en
10.500
10513010500
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground, polished, in 3m bars
pointed, chamfered, eddy current tested
diam. 10.50 mm, tolerance ISO h6
bars 3m
ground
h 6
0 kg
0
0
10-500
bars-3m
ground
h-6-en
3.050
10500703050
LAW 100 Pb
no 1.1268+Pb, ~AISI1095
freecutting leaded high carbon steel
precisely cold drawn, in coils
diam. 3.05 mm, tolerance ISO fg7
in spools
drawn
fg 7
0 kg
0
0
3-050
in-spools
drawn
fg-7-en
2.350
10500702350
LAW 100 Pb
no 1.1268+Pb, ~AISIi 1095
freecutting high carbon steel
cold drawn, in coils of ~25kg
diam. 2.35 mm, tolerance ISO fg7
in spools
drawn
fg 7
0 kg
0
0
2-350
in-spools
drawn
fg-7-en
3.500
10500603500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in coils of apprx. 25kg
diam. 3.50 mm, tolerance ISO fg6
in spools
drawn
fg 6
0 kg
0
0
3-500
in-spools
drawn
fg-6-en
5.750
10513005750
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl. 4
diam. 5.75 mm, tolerance ISO h6
bars 3m
ground
h 6
0 kg
0
0
5-750
bars-3m
ground
h-6-en
5.650
10513005650
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, ground, polished
in 3m bars (+40/0mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl. 4
diam. 5.65 mm, tolerance ISO h6
bars 3m
ground
h 6
0 kg
0
0
5-650
bars-3m
ground
h-6-en
0.600
10502900600
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
precisely cold drawn, in 2m bars
diam. 0.60 mm, tolerance ISO h5
bars 2m
drawn
h 5
43 kg
0
191 207 - 42.522
0-600
bars-2m
drawn
h-5-en
1.300
10502001300
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
diam. 1.30 mm, tolerance ISO h6
bars 2m
drawn
h 6
0 kg
0
0
1-300
bars-2m
drawn
h-6-en
1.300
10503201300
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 3m bars
diam. 1.30 mm, tolerance ISO h8
bars 3m
drawn
h 8
73 kg
0
120 717 - 73.300
1-300
bars-3m
drawn
h-8-en
6.300
10513006300
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, annealed,
ground, polished, stress relieved
in 3m bars (+40/0 mm)
end of bars: pointed, chamfered
100% eddy current crack tested cl. 4
diam. 6.30 mm, tolerance ISO 286-2/h6
bars 3m
ground
h 6
504 kg
0
210 224 - 504.000
6-300
bars-3m
ground
h-6-en
3.200
10500303200
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn wire, annealed
diam. 3.20 mm, tolerance ISO h9
in spools
drawn
h 9
0 kg
0
0
3-200
in-spools
drawn
h-9-en
0.860
10500800860
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
precisely cold drawn, tensile Rm 900-1000MPa
in coils of apprx. 20kg, coil ID 300mm
diam. 0.86 mm, tolerance ISO fg7
in spools
drawn
spec.
0 kg
0
0
0-860
in-spools
drawn
spec-en
3.000
10503903000
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
precisely cold drawn,
in 3m bars (+20/0 mm)
end of bars: pointed, chamfered,
diam. 3.00 mm, tolerance ISO h5
bars 3m
drawn
h 5
0 kg
0
0
3-000
bars-3m
drawn
h-5-en
2.500
10502202500
LAW 100 Pb
no 1.1268+Pb, ~Aisi 1095
freecutting high carbon steel
cold drawn, in 2m bars
pointed/chamfered
diam. 2.50 mm, tolerance ISO h8
bars 2m
drawn
h 8
0 kg
0
0
2-500
bars-2m
drawn
h-8-en
1.600
10513001600
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, annealed, ground polished,
stress relieved, RoHS conforme
in 3m bars (+30/0mm)
end of bars: chamfered
100% eddycurrent crack tested cl. 4
diam. 1.60 mm, tolerance ISO 286-2/h6
bars 3m
ground
h 6
516 kg
0
120 624 - 516.000
1-600
bars-3m
ground
h-6-en
3.000
10512103000
LAW 100 Pb/20AP
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground, polished,
in 2m bars (0/-20 mm)
diam. 3.00 mm, tolerance ISO h7
bars 2m
ground
h 7
402 kg
0
101 022 - 180.800|091 022 - 221.350
3-000
bars-2m
ground
h-7-en
2.000
105121020001
LAW 100 Pb/20AP
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, ground, polished,
in 2m bars (0/-20 mm)
diam. 2.00 mm, tolerance ISO h7
bars 2m
ground
h 7
0 kg
0
0
2-000
bars-2m
ground
h-7-en
1.900
10500301900
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, in coils of 20-25kg
diam. 1.80 mm, tolerance ISO h9
in spools
drawn
h 9
0 kg
0
0
1-900
in-spools
drawn
h-9-en
1.300
10512901300
LAW 100 Pb
no 1.1268+Pb, ~AISI 1095
freecutting high carbon steel
cold drawn, annealed, ground, polished,
in 2m bars (+20/0mm)
diam. 1.30 mm, tolerance ISO h5
bars 2m
ground
h 5
424 kg
0
210 224 - 424.100
1-300
bars-2m
ground
h-5-en
2.200
10513102200
Brief description
Klein designation:
LAW 100 Pb
Class of steels:
hardenable free machining steel
with additions of S and Pb
Material number:
~ 1.1268+S and Pb
Standard AISI:
~ 1095; A100Pb
RoHS 2 – 2011/65/EU:
compliant
Machinability:
good up to very good
Hardening capability:
up to 64-66 HRc
Polishing ability:
not adapted for mirror polishing
Welding ability:
not adapted
Uses:
parts for watch movements and parts
and numerous industrial applications
LAW 100 Pb, A100 Pb, ~ AISI 1095 free cutting high carbon steel, (1.0 % C) non stainless, RoHS compliant.
Specially adapted for making parts in the watch industry, but also for other high precision small parts.
